KATANA
Available Models ✅
Katana 8-Port
Katana 16-Port
How to find the perfect model for your needs 😍
Here is a short guide that will help you pick the right Katana for you.
The Katana series offers high-performance network switches in two models: 8-Port (Katana) and 16-Port (Katana Pro). Both support PoE management, multi-channel IP camera recording, and H.264/H.265 playback.
Katana 8-Port
- CPU: Intel Alder Lake i3 (optional i5)
- RAM: DDR5, 8GB x2 (Optional 16GB x2)
- PoE Ports: 8 x RJ-45, 120W total
- IPCAM Throughput: Avg 320Mbps, Peak 420Mbps
- HDD Slots: 1 x 3.5” SATA
- Display Output: 1x DisplayPort, 2x HDMI (4K60Hz)
Katana Pro 16-Port
- CPU: Intel Alder Lake i5 (standard, optional i3/i7/i9)
- RAM: DDR5, 8GB x2 (Optional 16GB x2)
- PoE Ports: 16 x RJ-45, 240W total
- IPCAM Throughput: Avg 640Mbps, Peak 840Mbps
- HDD Slots: 4 x 3.5” SATA
- Display Output: 2x DisplayPort, 2x HDMI (4K60Hz)
Common Features
- OS: Linux standard, Windows optional
- Boot Drive: M.2 SSD 128GB (Optional: 256GB/512GB)
- AI Accelerator: Hailo M.2 module
- PoE Management & Monitoring
- Supports H.264/H.265 Recording & Playback
- Multi-channel IP Camera Support (3MP/5MP/4K)
